KNX IO 536 CC
Part Number: 5354
Price: £144.45
Description
KNX IO 536 CC – KNX LED dimming actuator 4-fold with constant current
Compact 4-fold dimming actuator with RGB, RGBW and Tunable White (TW) functions. The dimming actuator can be used e.g. for LED panels/strips with RGB / RGBW / Tunable White or for 4 independent dimming channels.
- Output for 12-24 V⎓ / 6 A, freely distributable (for CV), PWM dimmer
- Scenes, sequencer, staircase function, adjustable dimming curve
- Integrated logic and timer functions
- Connections: KNX, plugable screw terminals for IO
- For DIN rail, width 1 unit (18 mm)
