Sensor module for operating electrical fan coil units in KNX installations
Measurement and feedback control of the room temperature
Installation in flush-box according to DIN 49073 (recommendation: deep box)
Product characteristics
Real glass front panel
8 capacitive sensor buttons
Internal temperature sensor
External temperature sensor can be evaluated
Control of fan coil units
Heating and/or cooling mode
Suitable for 2-pipe or 4-pipe systems
Up to 3 fan speeds can be controlled
Room temperature controller function
Preselection of the current energy level either through the option of 4 operating modes in accordance with KNX standard or of 5 temperature profiles for use in hotels or similar sites
Display for indication of temperature (°C or °F), fan speed, operating mode/profile
1 operating level and 2 menu levels
Menu levels blockable
1 status LED (red/green/blue)
Brightness and contrast adjustable
Duration of the display illumination up to 120 seconds
Operation as extension unit for temperature controller possible
Integrated bus coupling unit
Are you looking for a different colour?
JUNG offer more colours than we are showing on the website:
LS RANGE-WHITE - Temperature controller fan coil White ref.no.: TRD LS 9248 WW
A / AS RANGES-WHITE - Temperature controller fan coil White ref.no.: TRD A 5248 WW
A / AS RANGES-BLACK - Temperature controller fan coil Black ref.no.: TRD A 5248 SW
